KNOBY — Precision Instruments

what it is

everylivingplantgeneratesbioelectricsignals.tinyvoltagefluctuationsthatshiftwithlight,moisture,touch,andtime.T1N-P0TcapturesthesesignalsandconvertsthemintoMIDIdatainrealtime.theresultismusicthatnohumancomposed.youchoosethescale,thesound,therouting.theplantdoestherest.

sensing

listening at
the microvolt
level.

two stainless steel electrodes make gentle contact with your plant’s stem or leaves. they measure bioelectric impedance — the plant’s internal resistance to a tiny oscillating signal.

this isn’t a soil sensor pretending to make music. it’s a direct reading of your plant’s electrical state.

methodbioelectric impedance

sampling100ms intervals

signal chain

from biology
to MIDI.

an NE555 timer circuit generates a precision oscillating signal. the plant’s impedance modulates it. an ESP32-S3 with 16MB flash and 8MB PSRAM samples the result and maps it to MIDI parameters: pitch, velocity, modulation, timing.

oscillatorNE555 astable circuit

processorESP32-S3 / dual-core / 240MHz

scales13 musical scales, 4 presets

mappingsame signal, same note. no fakery.

connectivity

plug in
anywhere.

USB MIDI connects directly to any DAW — ableton, logic, bitwig, you name it. BLE 5.0 sends wireless MIDI to your phone, tablet, or any bluetooth-capable synth. wifi streams data to the companion app. three protocols. zero drivers. works the moment you plug it in.

01USB MIDI

plug into any DAW. class-compliant. zero drivers. TinyUSB composite CDC + MIDI.

02BLE 5.0

wireless MIDI to phone, tablet, or any bluetooth-capable synth. low-latency.

03WiFi

streams to the companion app via websocket. real-time sensor dashboard. OTA firmware updates.

built-in audio

no laptop
needed.

T1N-P0T includes a PCM5102A DAC running at 44.1kHz / 16-bit stereo and an 8-voice polyphonic synthesizer. plug in headphones or a speaker and your plant is performing live.

0-voicepolyphonic synth

0.1 kHzsample rate / 16-bit

0effects built-in

0saveable presets

reverbschroeder algorithm. space and depth.

delaystereo ping-pong. 50–2000ms. rhythm.

chorusLFO-modulated. width and movement.

interface

one screen.
one knob.
zero clutter.

a 1.69-inch IPS LCD shows real-time data: current note, scale, signal strength, soil moisture, light level. a rotary encoder navigates every menu. a NeoPixel LED ring provides ambient status at a glance.

if it takes more than three clicks, we redesigned it.

display1.69" IPS LCD / 240x280px / ST7789V2

inputrotary encoder (EC11) + push button

statusWS2812B NeoPixel LED ring (RGB)

menus14 items / 4 saveable presets

materials

aluminum, ceramic,
twenty screws.

aluminum 6061anodized silver finish. laser-cut to 0.1mm tolerance. lightweight, corrosion-resistant.

stainless steel M320 A2-grade fasteners. visible, countable, honest. torqued to spec.

ceramic inserthand-formed plant vessel with proper drainage. glazed interior for root protection.

PA12 nylonSLS 3D-printed internal chassis. structural backbone. shock-absorbing mounting points.

silicone spacersfloat panels above chassis. vibration isolation. clean shadow lines between surfaces.

companion app

your plant,
your phone.

the knoby app connects via wifi or bluetooth. monitor your plant in real time. configure everything. get notified when your plant needs water. firmware updates happen over the air.

knoby appiOS + android

sensor dashboardsoil moisture, light levels, and temperature in real time.

MIDI configurationchoose scales, adjust mappings, save custom presets.

effects controlreverb, delay, chorus — all adjustable from your phone.

plant alertspush notifications when your plant needs water.

OTA updatesfirmware updates over wifi. no cable. no hassle.

cross-platformiOS + android. built with flutter.

specifications

the numbers.

core

processorESP32-S3, dual-core, 240MHz

memory16MB flash, 8MB PSRAM

sensorNE555 bioelectric impedance

sampling100ms intervals

scales13 musical, 4 user presets

firmwareFreeRTOS, 4 tasks, 2 cores

audio + connectivity

DACPCM5102A, 44.1kHz, 16-bit stereo

synthTinySoundFont, 8-voice poly

effectsreverb, delay (50–2000ms), chorus

output3.5mm TRS stereo jack

USBUSB-C / MIDI + charging

wirelessBLE 5.0 + WiFi

physical + interface

panelsaluminum 6061, anodized silver

fasteners20x stainless steel M3, A2

insertceramic with drainage

display1.69" IPS LCD, 240x280px

controlsrotary encoder + push button

indicatorsNeoPixel LED ring (RGB)

sensorssoil moisture, light (LDR), temp/humidity (DHT22)

dimensions~160 x 160 x 150mm

powerUSB-C + Li-Po battery

appiOS + android (flutter)

designed in warsaw, poland.

pre-order

get yours.

T1N-P0T ships Q3 2026. we’re launching on kickstarter to fund our first production batch of 1,000 units. early backers get priority shipping and the best price.

EUR 249–299free shipping within EU / worldwide at checkout

join waitlist

kickstarter Q3 2026 — delivery Q4 2026

in the box

T1N-P0T unit (aluminum panels + ceramic insert)
2x bioelectric electrode clips
USB-C cable (1m, braided)
quick start card
warranty card

no charger included. any USB-C power source works. we skipped the charger because you already have five.
